Technical Data:
Min Voltage Input:6V
Max Voltage Input:18V
PRV Activation:0-100PSI
Flow Rate:340LPH/40PSI(13.5V)
Current(40PSI):<13A(13.5V)
Horsepower Capabilities: Up to 800hp for naturally aspirated engines & 750hp for supercharged or turbo engines.
Mechanical Spec:
Overall Length (tip to tip): 5"(123MM)
Weight:12.6oz (360g)
Length of Pump Body Metal Case: 3 1/8"(80MM)
Pump Body Diameter: 1 1/2"(38MM)
Inlet Fitting: 7.7mm ID, 11.0mm OD
Outlet Fitting: 5/16" hose clamp
Specifications:
255LPH (43PSI), 190LPH (80PSI), Operating Pressure: 15-90 PSI, final fuel pressure set by regulator.
Flow Rate: 255LPH/43PS190LPH/80PSI
Working voltage:12V
Working pressure: 15-90PSI final fuel pressure set by regulator fuel pressure is set by the requlator
Applicable fuel: Gasoline, E85, and gasoline with an ethanol content lower than E85
